Borehole Report

HomeViewerImageryStreetTopo
Borehole Id 107U0062
County Panola (107)
Owner MDEQ - OFFICE OF LAND & WATER
Well Name PA-U-706
Driller
MISSISSIPPI GEOLOGICAL SURVEY
Drill Date
GridId 107U
Twn, Rng, Sec 27N - 2E - 9
Qtr Qtr NE/4,NE/4,NE/4,SE/4
OLWR Permit
Lat, Lon 34.22528, -90.08444
Remarks
STRATIGRAPHIC TEST HOLE
PLS District 0
PLSSectionCentroid 0,0
Available data may not be sufficient to properly map this borehole location.
Bit Size 5.000"
Elevation 173
Total Depth 200
Screen
Net Screen Interval Length
Screen Diameter
Static Water Level
Yield
Logger MOOG
Log: Min Depth 0
Log: Max Depth 194
Log Date
Log: Analog False
Log: Curves GR,SP,SPR,R8,16,32,64
Log: Unit LOGSHELL
Documents:
Digital Log 1 Inch
Digital Log 5 Inch
